ED2101插头插座量规
插头插座量规,插头插座量规优质厂商,插头插座量规最新供应,插头插座量规资讯,插头插座量规价格
- 详情
- 参数
- 评价
符合标准及条款
GB/T1002-2021《家用和类似用途单相插头插座 型式、基本参数和尺寸》
GB1003-2016《家用和类似用途三相插头插座 型式、基本参数和尺寸》
GB/T2099.1-2021《家用和类似用途插头插座 第1部分：通用要求》第9.1条款
GB17465.1-2022《家用和类似用途器具耦合器 第1部分：通用要求》第9.1条款
IEC60320-1:2021《Appliances couplers for household and and similar general purposes- Part1:General requirements》clause 9.1
IEC60884-1:2006《Plugs and socket-outlets for household and similar purposes- Part1:General requirements》clause 9.1
UL498-2016《Attachment Plugs and Receptacles》
DIN VDE 0620-1：2010《Plugs and socket-outlets for household and similar purposes - Part 1: General requirements on fixed socket-outlets》
BS1363-1-2012《13A plugs,socket-outlets,adaptors and connection units Part1:Specification for rewirable and non-rewirable 13A fused plugs》
AS/NZS 3112-2011《Approval and test specification – Plugs and socket-outlets》
SANS 164-1:2016《SOUTH AFRICAN NATIONAL STANDARD Plug and socket-outlet systems for household and similar purposes for use in South Africa Part1：Coventional system,16A 250V a.c》
SANS 164-2:2006《SOUTH AFRICAN NATIONAL STANDARD Plug and socket-outlet systems for household and similar purposes for use in South Africa Part2：IEC system,16A 250V a.c》
SANS 164-3:2007《SOUTH AFRICAN NATIONAL STANDARD Plug and socket-outlet systems for household and similar purposes for use in South Africa Part2：Coventional system,6A 250V a.c》
SANS 164-4:2007《SOUTH AFRICAN NATIONAL STANDARD Plug and socket-outlet systems for household and similar purposes for use in South Africa Part2：Dedicated system,16A 250V a.c》
试样范围、用途、原理、结构及使用环境
试样及限制：各国插头插座
试验用途：适用于对插头插座进行尺寸检查
测试原理：用量规对插头和插座进行形状及尺寸测量，以验证其是否符合标准范围
设备结构及特点：按标准
使用环境 -
性能指标
量规材料 进口工业级模具钢或不锈钢
测试项目 GB1002单相插头插座成套量规，图8-图16，共14件
GB1003三相插头插座成套量规，图5-图9，共24件
GB17465.1-2009(IEC60320-1:2007)耦合器量规，图2-图9T共24件,图22防变形检验片2件带支架，图27共6件
UL498-2012，Figure 9.1- Figure SD13.2，共21件
DIN VDE 0620-1：2010插头插座量规，Lehre1- Leher19b共35件，Bild14和Bild43共3件
BS1363-1-2012插头插座量规，图1-图33，共16件
AS/NZS 3112插头插座量, APPENDIX A- APPENDIX G,共15件，SH1412K及SH1413L各1件
SANS 164.1～161.4南非标准插头插座量规，共58件
IS 1293印度插头量规，FIG. B-1~ FIG. B-3共6件
